Features
350° horizontally rotatable and 90°vertically tiltable.
Non-flicker driver
Beam spreads 15° / 24° / 36° and 60° achieved with specialised optics and optical filters.
Selection of dimming drivers including 1-10V, Triac and DALI Dimmable CRI: Ra>80, Ra>90,
CCT: 2700K, 3000K, 4000K
Light Source:Philips/Osram/Bridgelux
CODE | POWER (W) | LUMEN (LM) | DIMENSIONS (MM) | DIMMABLE | BEAM ANGLE |
PU-TL-HP20 | 20 | 2000 | Φ90*H130 | no | 15°/24° 36°/60° |
PU-TL-HP25 | 25 | 2500 | Φ90*H130 | no | 15°/24° 36°/60° |
PU-TL-HP30 | 30 | 3000 | Φ90*H130 | no | 15°/24° 36°/60° |
PU-TL-HP35 | 35 | 3500 | Φ90*H160 | no | 15°/24° 36°/60° |
PU-TL-HP20 | 20 | 2000 | Φ90*H130 | 1-10V | 15°/24° 36°/60° |
PU-TL-HP25 | 25 | 2500 | Φ90*H130 | 1-10V | 15°/24° 36°/60° |
PU-TL-HP30 | 30 | 3000 | Φ90*H130 | 1-10V | 15°/24° 36°/60° |
PU-TL-HP35 | 35 | 3500 | Φ90*H160 | 1-10V | 15°/24° 36°/60° |
