Features
Non-flicker driver from LIFUD/PHILIPS /OSRAM
Zoomable beam spreads 15° to 60°
Selection of dimming drivers including 1-10V, Triac and DALI Dimmable CRI: Ra>80, Ra>90,
CCT: 2700K, 3000K, 4000K
Light Source: Philips/Osram/Bridgelux
CODE | POWER (W) | LUMEN (LM) | DIMENTIONS (MM) | CUT HOLE(MM) | DIMMABLE | BEAM ANGLE |
PU-DL-B7 | 7 | 700 | Φ85*H71 | φ75 | no | 15°/24°/38° |
PU-DL-B12 | 12 | 1200 | Φ85*H76 | φ75 | no | 15°/24°/38° |
PU-DL-B18 | 18 | 1800 | Φ85*H93 | φ75 | no | 15°/24°/38° |
PU-DL-B25 | 25 | 2500 | Φ105*H99 | φ95 | no | 15°/24°/38° |
PU-DL-B30 | 30 | 3000 | Φ130*H115 | φ120 | no | 15°/24°/38° |
PU-DL-B7 | 7 | 700 | Φ85*H71 | φ75 | 1-10V | 15°/24°/38° |
PU-DL-B12 | 12 | 1200 | Φ85*H76 | φ75 | 1-10V | 15°/24°/38° |
PU-DL-B18 | 18 | 1800 | Φ85*H93 | φ75 | 1-10V | 15°/24°/38° |
PU-DL-B25 | 25 | 2500 | Φ105*H99 | φ95 | 1-10V | 15°/24°/38° |
PU-DL-B30 | 30 | 3000 | Φ130*H115 | φ120 | 1-10V | 15°/24°/38° |
PU-DL-B7 | 7 | 700 | Φ85*H71 | φ75 | DALI | 15°/24°/38° |
PU-DL-B12 | 12 | 1200 | Φ85*H76 | φ75 | DALI | 15°/24°/38° |
PU-DL-B18 | 18 | 1800 | Φ85*H93 | φ75 | DALI | 15°/24°/38° |
PU-DL-B25 | 25 | 2500 | Φ105*H99 | φ95 | DALI | 15°/24°/38° |
PU-DL-B30 | 30 | 3000 | Φ130*H115 | φ120 | DALI | 15°/24°/38° |
